Cummins 4BT3.9-C80 SO11564 Parts Catalogue
Parts No | Parts Name |
---|---|
3927772 | BEARING,CRANKSHAFT THRUST |
3937214 | NOZZLE,PISTON COOLING |
A3901258 | GEAR,CRANKSHAFT |
C3901306 | BUSHING |
C3903920 | BLOCK,CYLINDER |
C3007635 | PLUG,EXPANSION |
C3900965 | PLUG,EXPANSION |
C3904217 | Screw,Hexagon Head Cap |
C3913917 | CAP,MAIN BEARING |
C3900068 | DOWEL,RING |
C3900257 | DOWEL, PIN |
C3900687 | PLUG,EXPANSION |
C3929016 | BEARING,MAIN |
C3929021 | BEARING,CRANKSHAFT THRUS |
C3929036 | Crankshaft,Engine |
C3919624 | PULLEY,ACCESSORY DRIVE |
A3960485 | GEAR,FUEL PUMP |
C3900630 | Screw,Hex flange headcap |
C3967107 | WASHER,PLAIN |
C3977315 | STUD |
C3977319 | CONNECTOR,MALE |
C3977321 | HOSE,FLEXIBLE |
C4932602 | BRACE,FUEL PUMP |
C4988581 | NUT,HEXAGON FLANGE |
C4991523 | SCREW,HEXAGON HEAD CAP |
C4991549 | SUPPORT,FUEL PUMP |
C3903380 | SEAL,BANJO CONNECTOR |
C3905307 | SCREW,BANJO CONNECTOR |
C4932532 | TUBE,FUEL DRAIN |
C4932608 | CONNECTOR,T |
C4934018 | MANIFOLD,FUEL |
C4988331 | TUBE,FUEL DRAIN |
Z3900023 | TUBE,INJECTOR FUEL SUPPL |
Z3900024 | TUBE,INJECTOR FUEL SUPPL |
A3903663ZZ | COVER,GEAR |
C4991305 | SEAL,OIL |
C4991307 | COVER,GEAR |
C3903475 | SEAL,RECTANGLE |
C3913995 | HOUSING,TIMING PIN |
C3903924 | PIN,TIMING |
C3904849 | RING,RETAINING |
C3913994 | SEAL,O RING |
C3915772 | SEAL,RECTANGLE |
C3938156 | GASKET,GEAR HOUSING |
C3960319 | GASKET,GEAR COVER |
C3960338 | HOUSING,GEAR |
C3284377 | ROD,PUSH |
C3920781 | Screw,hex flange head ca |
C3934920 | Support,Rocker lever |
C3931623 | TAPPET,VALVE |
C3283767 | GASKET,PUSH ROD COVER |
C3900630 | Screw,Hex flange headcap |
C3918612 | HOSE,PLAIN |
C3936188 | COVER,PUSH ROD |
C4935793 | Water Pump |
Parts No | Parts Name |
---|---|
C4928971 | CLAMP,T BOLT |
C3958258 | DAMPER,VIBRATION |
C4988455 | SPACER,CRANKSHAFT |
C4942479 | PLATE,COVER |
C4930315 | THERMOSTAT |
C4938600 | ALTERNATOR |
C3910923 | SUPPORT,ALTERNATOR |
C3285958 | BRACKET,BELT TENSIONER |
C3911568 | BELT,V RIBBED |
C3937553 | TENSIONER,BELT |
C4988361 | SUPPORT,FRONT ENGINE |
C4988362 | SUPPORT,FRONT ENGINE |
C3967250 | SENSOR,TEMPERATURE |
C3967251 | SENSOR,OIL PRESSURE |
C3967252 | SENSOR,SPEED |
C3914458 | FULLEY,FAN |
C4932907 | SUPPORT,FAN |
C4983776 | TUBE,AIR FUEL CONTROL |
C3925955 | ADAPTER,FILTER HEAD |
C3930942 | FILTER,FUEL |
C3931063 | FILTER,FUEL |
C4934663 | HEAD,FUEL FILTER |
C4988332 | TUBE,FUEL SUPPLY |
C3938159 | GASKET,REAR COVER |
C4933323ZZ | COVER,REAR |
3970548 | SEAL,OIL |
C4947579 | HOUSING,FLYWHEEL |
C4931801 | FAN,ENGINE |
C3973845 | PUMP,FUEL INJECTION |
C4937767 | PUMP,FUEL TRANSFER |
C4988330 | TUBE,FUEL SUPPLY |
C4941542 | HANDLE,SHUTOFF |
C4942879 | SOLENOID,FUEL PUMP |
C4939064 | FLYWHEEL |
C4988335 | PIPE,AIR TRANSFER |
C3977197 | BRACKET,LIFTING |
C3908616 | Cartridge,Lub oil filter |
C3957543 | CORE,COOLER |
C4932124 | GASKET,OIL COOLER CORE |
C4934218 | HEAD,LUB OIL COOLER |
C3933364 | DIPSTICK |
C3968986 | TUBE,OIL GAUGE |
C4937408 | PUMP,LUBRICATING OIL |
C3901049 | PAN,OIL |
C3905206 | Connection,Oil suction |
C3938162 | Gasket,Oil pan |
A3908179ZZ | PISTON,ENGINE |
C3904531 | RING,COMPRESSION PISTON |
C3918315 | Ring,Compression Piston |
C3920691 | RING,RETAINING |
C3932520 | Ring,Oil Piston |
C3942581 | Rod,Engine Connecting |
C3900919 | Screw,Connecting Rod |
C4891178 | Bushing |
C3973197 | CONNECTION,WATER INLET |
Parts No | Parts Name |
---|---|
C3971970 | BEARING,CONNECTING ROD |
C4991283 | PIN,PISTON |
A3914638 | CAMSHAFT |
A3907431 | GEAR,CAMSHAFT |
C3927155 | SUPPORT,CAMSHAFT THRUST |
C4928969 | KEY,PLAIN WOODRUFF |
A3919350 | INJECTOR |
C3909356 | Seal,Rectangular Ring |
3900250 | COLLET,VALVE |
C3283333 | GASKET,CYLINDER HEAD |
C3916691 | SPRING,VALVE |
C3920779 | Screw,Hex flange head ca |
C3926700 | SPRING,VALVE |
C3957912 | SEAL,VALVE STEM |
C3957913 | RETAINER,VALVE SPRING |
C3966450 | HEAD,CYLINDER |
C3812092 | Plug,Pansion |
C3966449 | HEAD,CYLINDER |
C4994143 | VALVE,EXHAUST |
C4995554 | VALVE,INTAKE |
C3919369 | GASKET,TURBOCHARGER |
C3960407 | TURBOCHARGER |
C4988354 | RELAY |
C4988412 | BRACKET,RELAY |
C4931779 | FLANGE,FAN CONNECTION |
C3930906 | Gasket,Valve cover |
C3937706 | GASKET,OIL DRAIN |
C3939258 | GASKET,COVER PLATE |
C3942915 | Gasket,filter head |
C4932124 | GASKET,OIL COOLER CORE |
C3971093 | ELBOW,MALE ADAPTER |
C4928803 | CLAMP,SPRING HOSE |
C4988423 | MUFFLER |
C4988425 | CONNECTION,TUR OIL DRAIN |
C4988449 | SWITCH,SELECTOR |
C4988450 | REGULATOR,VOLTAGE |
C4935789 | MOTOR,STARTING |
C3901635 | MANIFOLD,EXHAUST |
C3929881 | GASKET,EXHAUST MANIFOLD |
C3938153 | GASKET,INT MANIFOLD COVE |
C3938158 | GASKET, CONNECTION |
C4947828 | COVER,INTAKE MANIFOLD |
C4988334 | CONNECTION,AIR INTAKE |
RQ61901 | PLUG,PIPE |
C3281246 | Bracket,Lifting |
C3285102 | HOUSING,THERMOSTAT |
C3923331 | Gasket,Thm housing cover |
C4942951 | BRACKET,THROTTLE CONTROL |
C3937706 | GASKET,OIL DRAIN |
C3974113 | HOSE,FLEXIBLE |
C3977615 | CONNECTION,TUR OIL DRAIN |
C3901895 | CAP,FILLER |
C3928404 | Cover,Valve |
C3930906 | Gasket,Valve cover |
C3935449 | ISOLATOR,NOISE |
